The anti-theft system of modern cars usually adopts the method of monitoring the impact and vibration of the vehicle body for anti-theft warning, and the commonly used ones are magnetic effect sensors. Although it has good sensitivity, due to assembly and installation errors, its frequency response is unstable, resulting in reduced reliability of system alarms and a high false alarm rate. In addition, the method of towing or transporting the entire vehicle is also a commonly used means of stealing cars. The most effective way to deal with this theft method is to monitor the tilt angle of the vehicle body, but magnetic effect sensors cannot measure static acceleration, so it is impossible to monitor and warn against it. In short, there is now a need for more reasonable and reliable tilt sensors to replace them.

The mainstream uses MEMS technology to produce low-cost, low-power, single-chip integrated dual axis acceleration sensors. The LIS340 series tilt sensor is powered by a wide voltage range of 9-36V and can measure tilt angles within a range of ± 90 °. It has a resolution of up to 0.01 °, high impact resistance of 2000g, good electromagnetic interference resistance, reliability, and stability, low noise, and low temperature drift; It can simultaneously monitor the small vibrations of the vehicle body and the tilt angle of the entire vehicle. Applying it to car anti-theft systems not only expands the monitoring range of the system, but also simplifies the system and improves the reliability of anti-theft system reporting.

Usually, for theft methods such as trailer or whole vehicle handling, if the angle of the vehicle body changes by 5 degrees relative to the initial state, it can be determined that a theft has occurred. Connect the sensor to the wireless transceiver unit to promptly issue alarms or other information.

In addition, by measuring the small vibrations of the vehicle body, it is possible to monitor the behavior of damaging the vehicle body. If the energy of vibration exceeds the set threshold within a short period of time, it can be determined that there is damage to the car.
